Amphenol Aerospace

Amphenol - D38999/26WB35SN - Socket Size 11-13 Pin Female

P/N: D38999/26WB35SN

Product Code: ELE198C

Certificate Type: Certificate of Conformity (CoC)

69,90 $

Amphenol‘s TV-CTV Tri-Start MIL-DTL-38999 Series III connectors have high-density contact arrangements in a miniature circular shell.

In Stock

Fast Delivery

Domestic orders placed today will be delivered the next day or on the first following business day. Delivery to all EU countries via Serbia Post, DHL, FedEx, TNT or UPS.

Original Parts

We guarantee 100% authenticity of all aviation components. All products come directly from authorized manufacturers and distributors, with full documentation and certificates.

Expert Support

Our team of certified technicians is available for all your inquiries. Contact us by phone, email or live chat. Working hours: Mon-Fri, 08:00-18:00.

P/N D38999/26WB35SN

Product Code ELE198C

Product Category Electrical & Electronics

Certificate Type Certificate of Conformity (CoC)

Country of Manufacture United States

Delivery Usually within 1-2 weeks after placing order

Importer for Serbia Grappolo Aviation Supply Co. Ltd

Manufacturer Amphenol Aerospace

Amphenol‘s TV-CTV Tri-Start MIL-DTL-38999 Series III connectors have high-density contact arrangements in a miniature circular shell. Originally designed for the high-performance requirements of military and commercial aircraft, these circular connectors are perfect for applications requiring extremely reliable interconnections. Amphenol TV-CTV connectors are quick-mating and environmentally-sealed.

PRODUCT INFORMATION
Specification: MIL-DTL-38999
Sealing: IP67
Shielding: Yes
Connector Type: Circular
Connector Style: Plug
Mounting Type: Cable
Contacts, # of: 13
Contact Style: Socket
Termination Method: Crimp
Crimp Wire Gauge: 28, 26, 24, 22
Insert Arrangement: B35
Contact Size: 13#22D
Contacts Supplied: Yes
Contact Material: Copper Alloy
Contact Plating: 50 microinches Gold Plate
Shell Material: Aluminum Alloy
Shell Plating: Olive Drab Cadmium
Shell Color: Olive Drab
Insert Material: Hard Dielectric
Grommet & Seals Material: Silicone
Amperage Rating: 5A
Operating Voltage AC V RMS Max: 1300
Operating Temperature °F (°C): -85 to +347 (-65 to +175)
Contact Mating Life: 500
Insert Rotation/Keying: Normal
Service Rating: M
Export Class: EAR / EAR99
RoHS: No
Weight (lbs): Unknown
Weight (g): Unknown
