The LH Rotation / 30° Lag configuration refers to the magneto’s rotational direction and ignition retard setting. The lag feature delays spark timing during engine cranking to improve starting performance, then allows normal ignition timing once the engine is running. This makes the magneto especially suitable for applications where reliable engine starting and stable ignition timing are required.

Key Features
Manufacturer: Champion Aerospace
Brand/Series: Slick 6300 Series
Part Number: H6314
Description: Magneto – Left-Hand Rotation – 30° Lag – Overhauled (OHC)
Component Type: Aircraft engine ignition magneto
Condition: Factory Overhauled
Rotation: Left-hand (LH)
Lag Angle: 30°
Configuration: Impulse-coupled magneto
Application: Certified piston aircraft engine ignition systems
Function: Generates high-voltage ignition energy for aircraft spark plugs
Approval: FAA-approved aviation ignition component for applicable installations
Design Features:Compact and lightweight Slick magneto design
Sealed bearings for improved contamination protection
Reduced electromagnetic interference (EMI) for improved radio performance
Simplified internal timing system for easier maintenance
Durable construction for vibration and temperature environments found in aircraft engines

Benefits
Provides dependable ignition performance during all phases of flight operation
Improves engine starting reliability through impulse coupling technology
Maintains consistent spark energy for smooth engine operation
Reduces maintenance time through simplified inspection and timing procedures
Offers a cost-effective alternative to new magneto replacement through factory overhaul
Restores magneto performance while meeting aviation maintenance standards

Typical Applications
Certified general aviation piston aircraft
Aircraft equipped with Slick 6300-series ignition systems
Engine overhaul and magneto replacement programs
Applications requiring LH rotation and 30° lag timing configuration
Aircraft ignition systems requiring independent magneto operation

Specifications
Magneto Series: Slick 6300
Rotation: LH
Lag Setting: 30°
Configuration: Impulse coupled
Service Condition: Overhauled / inspected and tested
Dimensions (approx.): 11 × 9 × 6 in
Unit of Measure: Each
