Mini Circuits - ZFSC-2-1B+ - 2 Ways Power Splitter

Mini Circuits - ZFSC-2-1B+ - 2 Ways Power Splitter

P/N: ZFSC-2-1B+

Product Code: CON33C

Certificate Type: Certificate of Conformity (CoC)

Price on Request
The Mini-Circuits ZFSC-2-1B+ is a high-performance 2-way RF power splitter/combiner designed for broadband signal distribution and combining applications.

Fast Delivery

Domestic orders placed today will be delivered the next day or on the first following business day. Delivery to all EU countries via Serbia Post, DHL, FedEx, TNT or UPS.

Original Parts

We guarantee 100% authenticity of all aviation components. All products come directly from authorized manufacturers and distributors, with full documentation and certificates.

Expert Support

Our team of certified technicians is available for all your inquiries. Contact us by phone, email or live chat. Working hours: Mon-Fri, 08:00-18:00.

P/N ZFSC-2-1B+
Product Code CON33C
Product Category Connectors
Certificate Type Certificate of Conformity (CoC)
Country of Manufacture United States
Delivery Please add to cart for availability. If no stock delivery term is usually 3-4 weeks.
Importer for Serbia Grappolo Aviation Supply Co. Ltd
Manufacturer -N/A
Alternate P/N 02309-00

The ZFSC-2-1B+ uses a shielded case design with a mounting bracket for secure installation in rack, panel, and system-level applications. It delivers low insertion loss, excellent isolation between output ports, and balanced signal distribution, making it suitable for dividing one RF signal into two equal outputs or combining two signals into one port.

Key Features:

Genuine Mini-Circuits ZFSC-2-1B+ RF power splitter/combiner
2-way, 0° power division/combination
Frequency range: 5 to 500 MHz
Characteristic impedance: 50Ω
Bracketed shielded case for secure mounting
BNC connector configuration
Low insertion loss: approximately 0.3 dB typical
High isolation: approximately 28 dB typical
Excellent amplitude balance between output ports
Suitable for VHF/UHF, communication systems, and RF instrumentation applications
RoHS compliant design

Specifications:

Manufacturer: Mini-Circuits
Part Number: ZFSC-2-1B+
Component Type: 2-Way Power Splitter / Combiner
Frequency: 5–500 MHz
Impedance: 50Ω
Connector Type: BNC
Case Style: K18
Maximum Input Power (Splitter Mode): 1 W
Operating Temperature: -55°C to +100°C
