Product Properties
- Product Colour: Light Brown
- Brand: Ardrox
- Manufacturer Name: Chemetall GmbH
- Manufacturer Part Number: 50593763
- Also Known As: Dinitrol AV30 Penetrating Water Displacing Corrosion Inhibiting Compound
- Coverage: 17 m2 per Litre at 8 Micrometres
- Specific Film Weight: 30 g/m2
- CIC Penetration: Penetrating | Water Displacing
- Protection Time (Hours): 36
- Drying Time: 180 minutes
- Film Thickness: 30 to 50 Micrometres
- Flash Point (°C): 38

Specifications
NSN Reference 8030-12-338-4648
US Military MIL-PRF-16173 (Conforms)
Airbus AIMS 09-08-002
Boeing BMS 3-29
Airbus Helicopters CM CM0526
ATR CML 05-027N

Miscellaneous Specs
Bombardier BAMS 565-006 | Embraer MEP 10-063 | Kaman CMS CT-502

Please Note: Specifications and approvals are subject to change at any time. Users should always consult their AMM or the OEM when selecting products to ensure items have the release needed. Only specifications listed on the order confirmation will be certified on the Silmid CofC.

Product Information
Ardrox AV30 can be used in all areas of the airframe on painted and unpainted surfaces. It combines good penetration properties with excellent corrosion inhibiting characteristics at a low film weight.

Ardrox AV30 can be applied by dipping, brushing or spraying. For maximum penetration capability and the most effective corrosion inhibiting performance, spray application is recommended.

The coating should be applied at 50 to 100 µm / 2 - 4 mils wet thickness. Movable parts should be masked before treatment. If Ardrox AV30 spray control or masking of movable components is not possible, then an alternative soft waxy film CIC, such as Ardrox AV25 should be used.
