Mobil Jet™ Oil II was the first standard Type II oil on the market. After more than half a century, it continues to be the preferred oil of choice and is used in more than 50 percent of aircrafts in operation today.

This legendary, hassle-free, second-generation oil helps keep engines clean and operating at peak efficiency. Laboratory tests and engine inspections confirm it can handle extreme speeds, temperatures (up to 204 degrees Celsius/400 F) and stresses without breaking down.

Reasons to trust Mobil Jet Oil II

- It offers excellent deposit control, helping maintain engine cleanliness and reducing maintenance costs
- Provides superb elastomer compatibility, helping operators maximize component life and minimize oil consumption
- Offers exceptional wear performance, helping reduce component replacement costs and extend engine gear and bearing life
- Provides exceptional low-temperature fluidity and outstanding protection at high speeds
- It carries an extensive range of approvals, giving operators increased levels of flexibility

Features and benefits
Mobil Jet Oil II is formulated to meet the demanding requirements of aircraft-type gas turbines operating over a wide range of severe operating conditions. The product has a high specific heat in order to ensure good heat transfer from oil-cooled engine parts. In extensive laboratory testing and in-flight performance, Mobil Jet Oil II exhibits excellent bulk oil stability at temperatures up to 204ºC (400 ºF). The evaporation rate at these temperatures is low enough to prevent excessive loss of volume.

Key features and benefits include:

- Severe operating conditions
- Deposit control
- Foaming resistance
- Military use
- Wear protection
- Corrosion protection
- High/Low temperature viscosity

Applications
Mobil Jet Oil II is recommended for aircraft gas turbine engines of the turbo-jet, turbo-fan, turbo-prop, and turbo-shaft (helicopter) types in commercial and military service. It is also recommended for aircraft-type gas turbine engines used in industrial or marine applications. Mobil Jet Oil II is approved against the Standard Performance (STD) classification of U.S. Military Specification MIL-PRF-23699. It is also compatible with other synthetic gas turbine lubricants meeting MIL-PRF-23699. However, mixing with other products is not recommended because the blend would result in some loss of the performance characteristics of Mobil Jet Oil II. Mobil Jet Oil II is compatible with all metals used in gas turbine construction, as well as with F Rubber (Viton A), H Rubber (Buna N), and silicone seal materials.

Specifications and Approvals
Mobil Jet Oil II has the following builder approvals

Engines
-Honeywell/Lycoming-Turbine engines
-Rolls-Royce/Allison Engine Company
-CFM International
-General Electric Company
-IAE International
-Pratt and Whitney Group
-SNECMA
-Pratt and Whitney, Canada
-Rolls-Royce Limited
-Honeywell/Garrett-Turbine Engine Company
-Turbomeca

Accessories
-Honeywell-Auxiliary power units and air cycle machines
-Hamilton Standard-Starters
-Hamilton Sundstrand corp.- APUs, Constant-speed drives and integrated-drive generators

Mobil Jet Oil II is approved against
Mil-PRF-23699F-STD
PRI-QPL-AS5780/SPC

Typical Properties
Viscosity
cSt @ 40ºC (102ºF) 27.6
cSt @ 100ºC (212ºF) 5.1
cSt @ -40ºC (-40ºF) 11,000
% change @ -40ºC after 72 hours 0.15
Pour Point, ºC (ºF), ASTM D 97 -59 (-74)
Flash Point, ºC (ºF), ASTM D 92 270 (518)
Fire Point, ºC (ºF) 285 (545)
TAN (mg KOH/g sample) 0.03
Density @15 ºC, kg/l, ASMT D 4052 1.0035
Evaporation Loss, %
6.5 hr @ 204ºC, 29.5" Hg 3.0
6.5 hr @ 232ºC, 29.5" Hg 10.9
6.5 hr @ 232ºC, 5.5" Hg 33.7
(Equals pressure @ 40,000 Ft. altitude)
Foam, ml
Sequence I, 24ºC 8
Sequence II, 93.5ºC 10
Sequence III, 75ºC (after 200 F test) 8
Foam Stability, after 1 min settling, ml 0
Rubber Swell
F Rubber, 72 hr @ 204º C, % 15.6
H Rubber, 72 hr @ 70ºC, % 16.4
Sonic Shear Stability, KV @ 40ºC, change, % 0.9
Ryder Gear, Ave. lb/in % Hercolube A 2750 ,115

Equipment builders
CFM 56-5A/B
CFM 56-5B
CFM 56-7B
CFM Leap-1A
CFM 56-5C
Engine Alliance (EA) GP7200
GE CF34-10
GE Aviation CF34-10E
GE Aviation CF34-3
GE Aviation CF34-8
GE Aviation CF6-50
GE Aviation CF6-80C2
GE Aviation CF6-80E1
GE Aviation GE90
GE Aviation GEnX-1B
GE Aviation GEnX-2B
Hamilton Sundstrand/UTAS IDG
Hamilton Sundstrand/UTAS VFSG
Hamilton Sundstrand/UTAS VFG
Hamilton Sundstrand/UTAS APS 1000
Hamilton Sundstrand/UTAS APS 2000
Hamilton Sundstrand/UTAS APS 2300
Hamilton Sundstrand/UTAS APS 2600
Hamilton Sundstrand/UTAS APS 3200
Hamilton Sundstrand/UTAS APS 500
Hamilton Sundstrand/UTAS Starters
Honeywell 131-9
Honeywell 131-9B
Honeywell 131-9C
Honeywell 331-200
Honeywell 331-350
Honeywell 331-500/600
Honeywell GTCP-36-300
Honeywell GTCP-85
Honeywell HGT-1700
Honeywell HGT-750
Honeywell RE220
International Aero Engines (IAE) V2500
Pratt & Whitney - PW1100G-JM
Pratt & Whitney - PW1500G
Pratt & Whitney - PW2000
Pratt & Whitney - PW4000
Pratt & Whitney - PW6000
Pratt & Whitney - Canada 127
Pratt & Whitney - Canada 150
Pratt & Whitney - Canada 901
Pratt & Whitney - Canada 980
Pratt & Whitney - JT8-D
Rolls Royce - RB211-500
Rolls Royce Trent 500
Rolls Royce Trent 700
Rolls Royce Trent 800
Rolls Royce Trent 900
Rolls Royce/Allison Engines 3007
Aerolec VFG
Turbomeca
Pratt & Whitney - PW 1400G-JM
CFM Leap - 1B
CFM Leap - 1C
Rolls Royce - RR BR715
GE Aviation CF6-6
GE Aviation 9X
Pratt & Whitney - JT9-D
Ptatt & Whitney - PW1700G
Ptatt & Whitney - PW1900G
Honeywell GTC - 660
Honeywell HW TSCP-700
Safran
